Bellows

Specifications:

  • Size – 25NB (1″) TO 600 NB (24″)
  • Material – PTFE



Technical Specification
PTFE Membrane: Paste extruded
PTFE Liner as ASTM D 4895		 Flange Drilling: as per ASME
B16.5 /DIN/JIS with one side off
Center & other side on center
Reinforcement rings: SS304 / SS316 Paint: 2 coats of red oxide / hot
Dip galvanized / powder coated /
Specified by customer
Flange Material IS2062 / A516 /
SS316 / A216 WCB, PP / PVC
Note: Other than above length mentioned we do manufacture standard length bellows like as 100, 150, 200, 300 & 500
* All size products in single piece construction.
* All Dimensions are in millimeter
